Beschrijving
GEEN Antenne aanwezig.
GEEN Power connector aanwezig.
|
System
|
|
|
CPU
|
32-bit 150MHz RISC Processor with MMU
|
|
Flash
|
2+8 MB ( 2MB for Bootloader )
|
|
RAM
|
32M Bytes SDRAM
|
|
EEPROM
|
2K Bytes
|
|
Watchdog
|
Hardware built-in
|
| Ethernet | |
|
Compliance
|
IEEE802.3
|
|
Port
|
1-port
|
|
Transmission Rate
|
10/100Mbps Auto-detection
|
|
Connector
|
RJ-45
|
|
Auto MDI/MDI-X
|
Yes
|
| WLAN | |
|
Compliance
|
IEEE802.11g/b
|
| Interface | Mini-PCI slot (for Wireless Module) |
|
WEP
|
64-bit / 128-bit data encryption
|
|
WPA
|
WPA/WPA2-PSK compatible ( Supported TKIP / AES encryption )
|
|
Modulation
|
CCK, DQPSK, DBPSK, OFDM ( 11g )
|
|
Tx Power
|
11b: 15dBm / 11g: 14dBm
|
|
Rx Sensitivity
|
-66dBm@54Mbps / -80dBm@11Mbps
|
|
Transmission Rate
|
54Mbps ( max. ) with auto fallback
|
|
Transmission Distance
|
Up to 300 meters ( @12Mbps in open areas )
|
|
Topologies
|
Infrastructure, Ad-Hoc
|
|
Antenna connector
|
Reverse SMA
|
| Access Point | |
|
Other
|
AP/WDS/Bridge and hybrid
|
| Power | |
|
Input
|
DC 9 ~ 48V
|
|
Connector
|
3-pin terminal block
|
|
Consumption
|
Max. 4.5 W (Tx Mode) |
| Environment | |
|
Operating
|
0°C ~ 65°C ( 32° ~ 149°F )
|
|
Storage
|
-40° ~ 85°C ( -40°~ 185°F ), 5 ~ 95%RH
|
| Dimension | |
|
W x H x D
|
45mm x 91mm x 80mm
|
| Software | |
|
Configuration
|
Web Page / Windows utility
|
|
Support Protocol
|
TCP/IP, DHCP, DNS, NTP, SNMP, HTTP
|
