Beschrijving
Mechanical features
- Housing material
- PA 6.6 (synthetic)
- Housing design
- Cuboid
- Active area material of sensor
- PA 6.6 (synthetic)
- Degree of protection (IP)
- IP67
- Pressure-proof
- no
- Sensor length
- 6mm
- Ambient temperature
- -25 – 70°C
- Mechanical mounting condition for sensor
- Non-flush
- Material of cable sheath
- PUR (Polyurethane)
- Sensor width
- 10mm
- Sensor height
- 27mm
Electrical features
- Voltage type
- DC
- Max. output current
- 200mA
- Switching distance
- 3mm
- Type of switching output
- PNP
- With monitoring function of downstream devices
- no
- IO-Link compatible
- no
- Cascadable
- no
- Suitable for safety functions
- no
- Type of electrical connection
- Cable
- Type of switching function
- Breaker contact
- Supply voltage
- 10 – 30V
