Beschrijving
Output voltage
- DC 24V Nominal
Adjustment range
- 24 – 28V Factory setting 24.1V
Output current
- 12.0 – 10.3A Below +45°C ambient
- 10.0 – 8.6A At +60°C ambient
- 7.5 – 6.5A At +70°C ambient
Derate
- linearly between +45°C and +70°C
Input voltage
- AC 3AC 380-480V -15%/+20%
Mains frequency
- 50-60Hz ±6%
Input current
- AC 0.7 / 0.6A At 3×400 / 480Vac
Power factor
- 0.53 / 0.52 At 3×400 / 480Vac
AC Inrush current
- 4 / 4Apk At 3×400 / 480Vac
Efficiency
- 92.8 / 92.9% At 3×400 / 480Vac
Losses
- 18.6 / 18.3W At 3×400 / 480Vac
Hold-up time
- 34 / 54ms At 3×400 / 480Vac
Temperature range
- -25°C to +70°C
Size (WxHxD)
- 62x124x117mm Without DIN-rail
Weight
- 750g / 1.65lb
