Beschrijving
Output voltage
- DC 48V nominal
Adjustment range
- 48 – 54V
Output current
- 20 – 17.8A continuous
- 30 – 26.7A short term (4s)
Output power
- 960W continuous
- 1440W short term (4s)
Output ripple
- < 150mVpp 20Hz to 20MHz
Input voltage
- 3AC 380-480V -15%/+20%
Mains frequency
- 50-60Hz ±6%
AC Input current
- 1.65 / 1.35A at 3×400 / 480Vac
Power factor
- 0.88 / 0.90 at 3×400 / 480Vac
AC Inrush current
- typ. 4.5A peak
Efficiency
- 95.4 / 95.2% at 3×400 / 480Vac
Losses
- 46.3 / 48.4W at 3×400 / 480Vac
Temperature range
- -25°C to +70°C operational
Derating
- 24W/°C +60 to +70°C
Hold-up time
- typ. 25 / 25ms at 3×400 / 480Vac
Dimensions
- 110x124x127mm WxHxD
Weight
- 1500g / 3.3lb
