Specificaties
| Kenmerk | Waarde |
|---|---|
| Output Current | 40 A |
| Power Rating | 960W |
| Electrical Phase | 3 |
| Type | Switch Mode |
| Dimensions | 280 x 92 x 180mm |
| Width | 92mm |
| Minimum Temperature | 0°C |
| Mounting Type | DIN Rail |
| Efficiency | 90% |
| Maximum Temperature | +55°C |
| Ripple And Noise | 150mV Pk-Pk |
| Depth | 180mm |
| Weight | 3.6kg |
240 to 960W Three Phase
Compact and lightweight
Easily snaps onto 35mm Din rail
3 phase input 3 x 400/500Vac
Power factor correction to EN61000-3-2
RFI to EN55022-B
Fully regulated output
Adjustable output voltage
Short circuit protection/current limit
Parallelable (up to 5 units)
Easy connection-screw terminals
LED output indicators
Approvals
UL Listed; UL Listed for Canada
Approvals
UL Listed; UL Listed for Canada
Standards
UL, CSA, SELV, EN
